KNS Shop 購物價惠：
** 部份地區免費送貨
** 電話技術支援安裝
** 保證原庄跟機配件
** 提供七天售後保障 (只限非人為損壞)
KNS承諾所有網路攝影機均屬全新香港行貨 ㊣
並享有原廠保用服務 (條款以代理商提供為準)
*所有地區加$380包基本安裝服務, 第2支起加$300
請即致電 3170 7019 或電郵至 info@knshk.com 查詢及訂購。
System Information
| CPU |
- Multimedia SoC (System-on-Chip)
|
| Flash |
|
| RAM |
|
|
Camera Features
| Image sensor |
|
| Maximum Resolution |
|
| Lens Type |
|
| Focal Length |
|
| Aperture |
- F1.2 (wide) ~ F2.5 (tele)
|
| Auto-iris |
|
| Field of View |
- 28.2° ~ 115.3° (horizontal)
- 21.3° ~ 84.2° (vertical)
- 35.5° ~ 150.2° (diagonal)
|
| Shutter Time |
- 1/5 sec. to 1/32,000 sec.
|
| WDR Technology |
|
| Day & Night |
- Removable IR-cut filter for day & night function
|
| Minimum Illumination |
- 0.02 Lux @ F1.2 ( Color )
- 0.001 Lux @ F1.2 ( B/W )
|
| Pan / Tilt / Zoom |
- ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
|
| On-board Storage |
|
|
Video
| Compression |
|
| Maximum Frame Rate |
- H.264:
- 10 fps at 2560x1920
- 30 fps at 1920x1080
- MPEG-4:
- 10 fps at 1920x1536
- 25 fps at 1920x1080
- MJPEG:
- 13 fps at 2560x1920
- 30 fps at 1920x1080
|
| Maximum Streams |
|
| S/N Ratio |
|
| Dynamic Range |
|
| Video Streaming |
- Adjustable resolution, quality and bit rate
- Configurable video cropping for bandwidth saving
|
| Image Settings |
- Adjustable image size, quality and bit rate
- Time stamp, text overlay, flip & mirror
- Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, privacy masks
- Scheduled profile settings
|
|
Audio
| Audio Capability |
- Audio input/output (full duplex)
|
| Compression |
|
| Interface |
- Built-in microphone
- External microphone input
- External line output
|
| Effective Range |
|
|
Network
| Users |
- Live viewing for up to 10 clients
|
| Protocols |
- IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X
|
| ONVIF |
- Supported, specification available at www.onvif.org
|
|
Intelligent Video
| Video Motion Detection |
- Triple-window video motion detection
|
|
Alarm and Event
| Alarm Triggers |
- Video motion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection
|
| Alarm Events |
- Event notification using digital output, HTTP, SMTP, FTP and NAS server
- File upload via HTTP, SMTP, FTP and NAS server
|
|
General
| Smart Focus System |
- Focus assist button and OSD
|
| Connectors |
- RJ-45 cable connector for Network/PoE connection
- Audio input
- Audio output
- Video output
- AC 24V power input
- DC 12V power input
- Digital input*1
- Digital output*1
|
| LED Indicator |
- System power and status indicator
|
| Power input |
- 24V AC
- 12V DC
- IEEE 802.3af PoE Class 3
|
| Power consumption |
- Max. 4.87 W (DC 12V)
- Max. 7 W (AC 24V)
- Max. 6.8 W (PoE)
|
| Dimensions |
- 218 mm (D) x 72 mm (W) x 62 mm (H)
|
| Weight |
|
| Safety Certifications |
- CE, LVD, FCC Class A, VCCI, C-Tick
|
| Operating Temperature |
- Starting Temperature: 0°C ~ 50°C (32°F ~ 122°F)
- Working Temperature: -10°C ~ 50°C (14°F ~ 122°F)
|
| Warranty |
|
|
System Requirements
| Operating System |
- Microsoft Windows 7/Vista/XP/2000
|
| Browser |
- Mozilla Firefox 7~10 (Streaming only)
- Internet Explorer 7.x or 8.x
|
| Other Players |
- VLC: 1.1.11 or above
- Quicktime: 7 or above
|
|
備註：
1. 上門設定是包括有：網絡攝像機(IP Camera)和寬頻分享器之接駁 (包 6 呎以下電腦 CAT5 線) 連 IP 及 Port 位設定，免費動態網址(DDNS)之申請，測試網絡攝像機於內聯網 ( Intarnet ) 及互聯網 ( Internet ) 之運作是否正常，一部指定類別手提裝置監控設定協助。無線寬頻分享器之上網連接及無線設定連測試 (如一併購買)。
2. 上述之售價並不包括：錄影軟件之安裝，電腦維修及檢查，放線(釘線), 上鏍絲, 鑽牆, 掛機等工程項目；如果有需要掛機，請事前通知及先行報價後才可安排服務。
3. 上門基本安裝服務之地區：除了離島、機場或下車後步行時間多於15分鐘之路程外 (需另加HK$100-HK$200附加收費)；其他地區也可以，詳情請致電 3170 7019查詢。
4. 上門設定服務時間為：星期一至星期五，上午10:00至下午7:00，星期六至下午4:00，星期日及公眾假期休息。
5. 上門服務為一次過性質之服務，如有需要再次上門，收費為HK$350 (離島、機場或下車後步行時間多於15分鐘之路程除外)。
