KNS Shop 購物價惠：
** 部份地區免費送貨
** 電話技術支援安裝
** 保證原庄跟機配件
** 提供七天售後保障 (只限非人為損壞)
KNS承諾所有網路攝影機均屬全新香港行貨 ㊣
並享有原廠保用服務 (條款以代理商提供為準)
*所有地區加$380包基本安裝服務, 第2支起加$300
請即致電 3170 7019 或電郵至 info@knshk.com 查詢及訂購。
| Camera |
| Image Sensor: |
1/4" SONY Super HAD CCD |
| Effective Pixels: |
PAL:752(H)x582(V); NTSC:768(H)x494(V) |
| Horizontal Resolution: |
480TVL |
| Signal System: |
PAL/NTSC |
| Minimum Illumination: |
1.4Lux / F1.4 (Color); 0.01Lux / F1.4 (B/W) |
| White Balance: |
ATW / Manual |
| AGC: |
Auto/Manual |
| S/N Ratio: |
Better than 50dB |
| BLC: |
ON/OFF |
| Electronic Shutter: |
N: 1/4~1/10000s; P: 1/3~1/10000s |
| Day& Night: |
ICR |
| Digital Zoom: |
Up to 12x |
| Privacy Masking: |
Up to 24 zones, and support up to 8 zones masked simultaneously in 1 image |
| Auto Focus: |
Auto/Manual |
|
| Lens |
| Focal Length: |
3.4~122.4mm,36X |
| Zoom Speed: |
Approx. 4.0sec (Optical WIDE-TELE ) |
| Angle of View: |
57.8° to 1.7°(WIDE-TELE ) |
| Minimum Working Distance: |
320mm (WIDE); 1500mm(TELE) |
| Aperture Range: |
F1.4-F3.8 |
|
| Pan & Tilt |
| Pan Range: |
360° continuous |
| Pan Speed: |
Manual: approx. 0.3°/s-160°/s or 0.3°/s-220°/s |
| Tilt Range: |
0°~90° , support auto flip |
| Tilt Speed: |
Manual: approx. 0.5°/s-40°/s or 0.5°/s-60°/s |
| Proportional Zoom: |
Support |
| Number of Preset: |
200 |
| Patrol: |
8 |
| Pattern: |
4 |
| Power-off Memory: |
Support |
| Park Action: |
Call Preset/Patrol/Pattern/Auto Scan/Random Scan/Frame Scan after a pre-defined inactivity time interval |
| PTZ Position Display: |
ON/OFF |
| Freeze Frame: |
Support |
|
| Alarm |
| Alarm Input: |
2 channel signal input with adjustable priority |
| Alarm Output: |
2 channel relay output, with configurable alarm actions |
| Alarm Actions: |
Preset 1 ~ 200, Patrol 1 ~ 8, Pattern 1 ~ 4, SD card recording, Terminal output, Notification on Client |
|
| Input & Output |
| Monitor Output: |
1.0Vp-p, 75 Ohm, BNC |
| Audio Input: |
1 channel Mic. Input (applicable microphone, plug-in power type), 2.0~2.4Vp-p, 1k Ohm±10% |
| Audio Output: |
1 channel audio output, linear level |
|
| Network |
| Ethernet: |
10Base -T, /100Base-TX, RJ45 Connector |
| Max.Image Resolution: |
PAL:704x576; NTSC: 704x480 |
| Frame Rate: |
25fps (704×576) |
| Image Compression: |
H.264 |
| Audio Compression: |
OggVorbis, 16Kbps |
| Audio Mode: |
OFF/Audio input/Audio output |
| Protocols: |
TCP/IP |
| No. of Simultaneous Users: |
Up to 6 user connections at the same time |
| Dual Stream: |
Support |
| Mini SD Card: |
Manual record/Alarm record. Compatible with SDHC standard cards. |
| Security Measures: |
User authentication (ID and password), Host authentication (MAC) |
|
| Client GUI |
| Camera Control: |
Pan/Tilt, Zoom, Focus, Click centering, Zoom by mouse dragging, Iris, preset calling and programming, auto mode |
| Clock Display: |
Time: Week: Date, 6 formats on the Client |
|
| General |
| Menu Language: |
English / Chinese |
| RS-485 Protocols: |
Hikvision, Pelco-P, or Pelco-D protocols (protocol types can be extended) |
| Power Supply: |
24V AC (12V DC optional) |
| Power Consumption: |
30W Max (Heater ON) |
| Working Temperature/Humidity: |
-30°C ~ 60°C |
| Protection Level: |
IP66 with TVS 3000V lightning protection, surge protection and voltage transient protection |
| Dimensions: |
6 inch |
| Weight (approx.): |
5kg |
|
備註：
1. 上門設定是包括有：網絡攝像機(IP Camera)和寬頻分享器之接駁 (包 6 呎以下電腦 CAT5 線) 連 IP 及 Port 位設定，免費動態網址(DDNS)之申請，測試網絡攝像機於內聯網 ( Intarnet ) 及互聯網 ( Internet ) 之運作是否正常，一部指定類別手提裝置監控設定協助。無線寬頻分享器之上網連接及無線設定連測試 (如一併購買)。
2. 上述之售價並不包括：錄影軟件之安裝，電腦維修及檢查，放線(釘線), 上鏍絲, 鑽牆, 掛機等工程項目；如果有需要掛機，請事前通知及先行報價後才可安排服務。
3. 上門基本安裝服務之地區：除了離島、機場或下車後步行時間多於15分鐘之路程外 (需另加HK$100-HK$200附加收費)；其他地區也可以，詳情請致電 3170 7019查詢。
4. 上門設定服務時間為：星期一至星期五，上午10:00至下午7:00，星期六至下午4:00，星期日及公眾假期休息。
5. 上門服務為一次過性質之服務，如有需要再次上門，收費為HK$350 (離島、機場或下車後步行時間多於15分鐘之路程除外)。
