- Product Segment
AC1200 enhanced AC performance : 300+867 Mbps
- Coverage
Large homes
- Data Rate
802.11n : up to 300 Mbps
802.11ac : up to 867 Mbps
- Antenna
Detachable dipole antenna x 2
*Antenna type will differ according to local regulations and requirement in each country
- Transmit/Receive
MIMO technology
2.4 GHz 2 x 2
5 GHz 2 x 2
- Memory
128 MB Flash
128 MB RAM
- Operating Frequency
2.4 GHz / 5 GHz
- Encryption
64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , WPS support
- Firewall & Access Control
Firewall：SPI intrusion detection,DoS protection
Access control：Parental control, Network service filter, URL filter, Port filter
- Management
UPnP, DLNA, IGMP v1/v2/v3, DNS Proxy, DHCP, SNMP, NTP Client, DDNS, Port Trigger, DMZ, System Event Log
- WAN Connection Type
Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
WAN Bridge support
Multicast Proxy support
Multicast Rate Setting support
- Ports
RJ45 for 10/100/1000/Gigabits BaseT for WAN x 1, RJ45 for 10/100/1000/Gigabits BaseT for LAN x 4
USB 2.0 x 1
USB 3.0 x 1
- Button
WPS Button, Reset Button, Power Button
- Features
SmartQoS
- WMM
- User definable rules for IP/MAC/Port
- Upload and download bandwidth management
- ACK/SYN/FIN/RST/ICMP with highest priority
Parental Control
Guest Network : 2.4 GHz x 3, 5 GHz x 3
VPN server : IPSec Pass-Through, PPTP Pass-Through, L2TP Pass-Through, PPTP Server, OpenVPN Server
VPN client : PPTP client, L2TP client, OpenVPN client
Mac OS Backup
Enhanced media server (AiPlayer app compatible)
- Image : Jpeg
- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
AiCloud personal cloud service
3G/4G data sharing
Printer Server
- Multifunctional printer support (Windows only)
- LPR protocol support
Download Master
- Support bt, nzb, http, ed2k
- Support encryption, DHT, PEX and magnet link
- Upload and download bandwidth control
- Download scheduling
AiDisk file server
- Samba and FTP server with account management
Dual WAN
IPTV support
- LED Indicator
Power x 1
LAN x 1
Wi-Fi x 2
USB x 2
WAN x 1
WPS x 1
- Power Supply
AC Input : 110V~240V(50~60Hz)
DC Output : 12 V with max. 2 A current
- OS Support
Windows® 10
Windows® 8.1 , 32bit/64bit
Windows® 8 , 32bit/64bit
Windows® 7 , 32bit/64bit
Windows® Vista , 32bit/64bit
Windows® 2000 , 32bit/64bit
Windows® ME
Windows® XP , 32bit/64bit
Windows® Server 2003
Windows® Server 2008
Mac OS X 10.5
Mac OS X 10.6
Mac OS X 10.7
Mac OS X 10.8
Mac OS X 10.9
Mac OS X 10.10
Linux Kernel (Support Ubuntu only)
Linux
- Dimensions
207 x 148.8 x 35.5 ~ mm (WxDxH)
- Weight
- Package Content
RT-AC55UHP Dual-band Wireless-AC1200 Gigabit Router
RJ-45 cable
Support CD (user manual)
Power adapter
Quick Start Guide
2 detachable antennas
Warranty card
- Operation mode
Wireless router mode
Access point mode
Media bridge mode
