DISPLAY |
||
| Type | 0.55" Digital Micromirror Device (DLP™) | |
| Resolution | XGA 1024x768 (Native) | |
| Lens | Fixed Lens / Manual Focus | |
| Keystone | Vertical digital keystone correction: +/– 40 degrees | |
| Display size | 30"–300" / .762m–7.62m | |
| Throw Distance | 0.37m–3.7m / 1.2ft–12.21ft | |
| Throw Ratio | 0.61:1 | |
| Lamp type | 210 watt | |
| Lamp life (normal/eco-mode) | 4000 / 6000 hours | |
| Brightness | 3000 ANSI lumens | |
| Contrast Ratio | 2000:1 static (typ); 3000:1 (dynamic) | |
| Aspect Ratio | 4:3 (native) and 16:9 | |
| Brightness | 1,000 ANSI lumens | |
| Color Wheel | 6-Segment RGBCYW / 7200rpm | |
| Color Gamut | 90% NTSC 1931 CIE | |
| Color Depth | 24 bits, 16.7M color (8+8+8) | |
INPUT SIGNAL |
||
| Video | NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM (B, D, G, K, K1, L), SD 480i/576i, ED 480p/576p, HD 720p/1080i | |
| Frequency | Fh: 31–100KHz, Fv: 48–120Hz | |
COMPATIBILITY |
||
| PC | VGA to UXGA | |
| Mac® | Up to UXGA (scaled) | |
CONNECTOR |
||
| RGB Input | 15-pin mini D-sub (x2) | |
| Composite Input | RCA jack | |
| S-Video Input | 4-pin mini-DIN | |
| RGB Output | 15-pin mini D-sub | |
| Control | RS-232 (9-pin mini-DIN)/RJ-45 | |
| Audio (input/output) | 3.5mm mini jack (x1), RCA (L/R)x1 / 3.5mm mini jack | |
| USB | Type A for PC-less slide show presentation – supports JPEG, BMP, TIFF, PNG, GIF from USB flash drive, optional wireless USB adapter. Mini-B for direct presentation from PC (not MAC compatible) PointBlank, mouse control | |
| Mic-In | 3.5mm mini jack | |
| Screen Trigger | 3.5mm/1A | |
AUDIO |
||
| Speakers | 10W (x1) | |
POWER |
||
| Voltage | 100~240VAC (Auto Switching), 50/60Hz (universal) | |
| Consumption | 298W (typ) / 1W (stand-by mode) | |
CONTROLS |
||
| Basic | Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, auto, mode/enter, source | |
| OSD | Picture: Brightness, contrast, color setting, keystone, aspect ratio, image, white intensity, gamma, 3D sync, 3D sync invert Computer Image Picture: Brightness, contrast, color setting, keystone, aspect ratio, image, white intensity, gamma, 3D sync, 3D sync invert Computer Image: Frequency, tracking, H position, V position Video Image: Saturation, sharpness, tint Setting: Menu position, projection, signal type, lamp hour, lamp hour reset, filter mode, filter hours, filter hours reset, power saving, auto source, Eco-mode, high altitude, OSD timeout | |
OPERATING CONDITIONS |
||
| Temperature | 32ºF–104ºF (0ºC–40ºC) | |
| Humidity | 10%–90% (non-condensing) | |
| Altitude | 0~6,000 ft. (1,800m), operational up to 10,000 ft. (3048m) | |
NOISE LEVEL |
||
| Normal | 32dB | |
| Eco-mode | 27dB | |
DIMENSIONS (WxHxD) |
||
| Physical | 11.4" x 5.0" x 10.0" / 290mm x 126mm x 254mm | |
| Packaging | 15.0" x 8.3" x 15.4" / 380mm x 210mm x 392mm | |
WEIGHT |
||
| Net | 7.7 lb. (3.5 kg) | |
| Gross | 12.1 lb. (5.5 kg) | |
REGULATIONS |
||
| CB, UL, FCC (including ICES-003), CE, UL-Argentina, NOM, TUV-GS, GOST-R, SASO, Ukraine, PSB, C-Tick, Korean-eK, Hygiene, WEEE, RoHS | ||
PACKAGE CONTENTS |
||
| ViewSonic projector, power cable, VGA cable, laser remote control with batteries, lens cap, soft case, interactive pen, Quick Start Guide, ViewSonic Wizard CD (with User Guide) |
開箱不良包換期限: 購機14天包換
產品保養期:
2年自攜保養; 包括零件及人工費.
(燈泡屬於耗材部份，僅提供一年保養, 且使用時間700小時內。)
由2011年12月起購買之投影機可享以下升級保養服務:
3年免費上門收送，保養; 包零件及人工費。
(燈泡屬於耗材部份，僅提供一年保養,且使用時間700小時內。)
Both HK & Macau provide on-site service for projector.
*on-site service is meaning pick up & delivery, not on-site repair.
