DISPLAY |
||
| Type | 0.45" Digital Micromirror Device (DLP™) | |
| Resolution | WXGA 1280x800 (native) | |
| Lens | Fixed Manual optical zoom/Manual optical focus | |
| Keystone | Auto Vertical keystone correction, +/- 40º | |
| Display size | 30" - 100" / 0.76m - 2.54m | |
| Throw Distance | 2.9ft - 9.8ft / 0.9m - 3.0m | |
| Throw Ratio | 1.4:1 | |
| Lamp life (normal/eco-mode) | >20000 hours | |
| Brightness | 500 Lumens | |
| Contrast Ratio | 6000:1 | |
| Aspect Ratio | 16:10 (native), 16:9, 4:3, auto | |
| Color Gamut | 120% NTSC | |
| Color Depth | 1.07B Color (R/G/B 10bit) | |
INPUT SIGNAL |
||
| Computer and Video | NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N), SECAM ( B, D, G, K, K1, L), SD 480i and 576i, ED 480p and 576p, HD 720p, 1080i and 1080p | |
| Frequency | Fh: 31 -100KHz, Fv: 50 -120Hz | |
COMPATIBILITY |
||
| PC | VGA to WSXGA+ | |
| Mac® | Up to SXGA+ (scaled) | |
CONNECTOR |
||
| Digital | HDMI 1.3 | |
| RGB Input | 15-pin mini D- sub | |
| Composite Input | RCA jack | |
| S-Video Input | 4-pin mini-DIN | |
| Component | 15-pin mini D- sub (shared with RGB) | |
| RGB Output | 15-pin mini D-sub | |
| Control | RS-232 (DB-9) | |
| USB | Type A: for PC-Less Presentation support PowerPoint, Word, Excel,PDF, video, photo Mini B: for USB Display, file transfer, firmware update | |
| Audio | Audio Input - 3.5mm mini jack | |
| Card Reader | SDHC up to 32GB (for PC-Less Presentation support PowerPoint, Word, Excel,PDF, video, photo) Memory: 1GB (for media file storage, via Mini-B) | |
AUDIO |
||
| Speakers | 2W | |
POWER |
||
| Voltage | 100 ~ 240VAC (Auto Switching), 50/60Hz (universal) | |
| Consumption | <120W (typ) / 0.5W (stand-by mode) | |
CONTROLS |
||
| Basic | Power, arrow keys, source, menu | |
| OSD | Picture: Color Mode (Brightest /PC/ Movie/ Picture User)/Wall color (White/ Light yellow/ Light Blue/Pink/ Dark Green) / Brightness/ Contrast / Sharpness/ Saturation/ Hue/ Advanced (Gamma/ BrilliantColor/ Color Temp (low/ Middle/ High) / Color Space (Auto/ RGB/ YUV) Input (HDMI/ VGA/ Composite/ S-video/ AV/ USB display/ Exit) Screen: Aspect Ratio (Auto / 4:3 / 16:9 / 16:10) / Overscan / Digital Zoom / Auto Keystone / V Keystone / Ceil Mount Settings: Language / Location / (front / back) / Menu Position / Signal (Phase / Clock / H. Position / V. Position / Exit) / Mute / Volume / 3D / 3D invert / Advanced (Logo / Close Caption / Security / Exit) / Reset Options: Auto source / Fan Mode (AUTO / High Altitude) / Information Hide / Background Color (Black / Blue) / LED Settings (LED hours used / ECO mode / Clear LED hours / Exit / Information (Model name / Source / Resolution / Software Verison/ Color Space / Aspect ratio) / Advanced (Direct Power On / Auto Power off / Keypad Lock / Exit) / LED calibration | |
OPERATING CONDITIONS |
||
| Temperature | 32 F-104 F (0 C-40 C) | |
| Humidity | 10%-90% (non-condensing) | |
| Altitude | 0~6,000 ft (1,800m), operational up to 10,000 ft (3048m) | |
NOISE LEVEL |
||
| Normal | 36 dB | |
| Eco-mode | 32 dB | |
DIMENSIONS (WxHxD) |
||
| Physical | 8.4" x 1.6" x 6.4" (in) 214 x 42 x 164 (mm) | |
| Packaging | 13.9" x 9.8" x 5.5" (in) 353 x 250 x 140 (mm) | |
WEIGHT |
||
| Net | 2.6 lb. (1.18kg) | |
| Gross | 5.0 lb. (2.26kg) | |
REGULATIONS |
||
| RoHS, REACH, CB, CCC, CE(including C-tick standard), GOST-R, GS, PSB, cULus, FCC-B (including ICES003), UL AR-SMark, NOM | ||
PACKAGE CONTENTS |
||
| ViewSonic PLED-W500 projector, soft case, power cable, VGA cable, remote control with batteries, Quick Start Guide, ViewSonic Wizard CD (with User Guide) |
開箱不良包換期限: 購機14天包換
產品保養期:
2年自攜保養; 包括零件及人工費.
(燈泡屬於耗材部份，僅提供一年保養, 且使用時間700小時內。)
由2011年12月起購買之投影機可享以下升級保養服務:
3年免費上門收送，保養; 包零件及人工費。
(燈泡屬於耗材部份，僅提供一年保養,且使用時間700小時內。)
Both HK & Macau provide on-site service for projector.
*on-site service is meaning pick up & delivery, not on-site repair.
