DISPLAY |
||
| Type | 0.7" Digital Micromirror Device (DLP™) | |
| Resolution | 1920x1080 (1080p) | |
| Lens | 1.5× Manual optical zoom / Manual optical focus | |
| Keystone | Vertical digital keystone correction: +/– 20 degrees | |
| Display size | 30"–300" / 0.76m–7.6m | |
| Throw Distance | 0.9m–10m / 3ft–32.8ft | |
| Throw Ratio | 1.4 – 2.14:1 | |
| Lamp type | 280 watt | |
| Lamp life (normal/eco-mode) | 4000 / 5000* hours | |
| Brightness | 4000 ANSI Lumens | |
| Contrast Ratio | 2600:1 (typ), 3000:1 (dynamic) | |
| Aspect Ratio | 16:9 (native) and 4:3 | |
| Color Gamut | 70% NTSC 1931 CIE | |
INPUT SIGNAL |
||
| Computer and Video | NTSC M (3.58 MHz), 4.43MHz, PAL (B, D, G, H, I, M, N, 60), SECAM (B, D, G, K, K1, L), SD 480i and 576i (24fps, 25fps and 30fps), ED 480p and 576p (24fps, 25fps and 30fps), HD 720p, 1080i and 1080p (24fps, 25pfs and 30fps) | |
| Frequency | Fh: 31–91KHz, Fv: 48–85Hz | |
COMPATIBILITY |
||
| PC | VGA to 1080p | |
| Mac® | Up to 1080p | |
CONNECTOR |
||
| Digital | HDMI 1.3 (x2) | |
| Network | RJ-45 | |
| Composite Input | RCA jack | |
| S-Video Input | 4-pin mini-DIN | |
| Component | RCA (x3) | |
| Control | RS-232 (DB-9) | |
| RGB (input/output) | 15-pin mini D-sub (x2) / 15-pin mini D-sub | |
| Audio (input/output) | 3.5mm mini jack / 3.5mm mini jack | |
| USB | Mini-B for direct presentation from computer Type A supports JPEG, BMP, TIFF, PNG, GIF from USB flash drive | |
| Screen Trigger | 0.35 plug (12V/1A) | |
AUDIO |
||
| Speakers | 10W (x2) | |
POWER |
||
| Voltage | 100~240VAC (Auto Switching), 50/60Hz (universal) | |
| Consumption | 360W (max) / <1W (stand-by mode) | |
CONTROLS |
||
| Basic | Power, keystone/arrow keys, left/blank, menu/exit, right/panel key lock, auto, mode/enter, source | |
| OSD | Picture: Brightness, Contrast, Color Setting, Keystone, Aspect Ratio, Image, White Intensity, Gamma Computer Image: Frequency, Tracking, H Position, V Position Video Image: Saturation, Sharpnes, Tint Setting: Menu Position, Projection, Signal Type, Lamp Hour, Lamp Hour Reset, Filter Mode, Filter Hours, Filter Hours Reset, Power Saving, Auto Source, Eco-mode, High Altitude, OSD Timeout Advance: Blank Screen, Password Word, Screen Capture, Start up Screen, Digital Zoom, DCR, Close Captions | |
OPERATING CONDITIONS |
||
| Temperature | 32ºF–104ºF (0ºC–40ºC) | |
| Humidity | 10%–90% (non-condensing) | |
| Altitude | 0~6,000 ft (1,800m), operational up to 10,000 ft (3048m) | |
NOISE LEVEL |
||
| Normal | 33dB | |
| Eco-mode | 29dB | |
DIMENSIONS (WxHxD) |
||
| Physical | 13.1 × 4.8 × 10.4 (in) / 332.7× 121.9 × 264.2 (mm) | |
| Packaging | 16.3 × 7.5 × 14.8 (in) / 414 ×190.5 × 375.9 (mm) | |
WEIGHT |
||
| Net | 8.5 lb (3.86 kg) | |
| Gross | 11.8 lb (5.36 kg) | |
REGULATIONS |
||
| CB, RoHS, SVHC, WEEE, UL/cUL, FCC-B, ICES-004, TUV-S (Argentina), NOM, PSB, C-tick, KC, CE, GOST-R, Hygienic, UKrSEPRO, CCC | ||
PACKAGE CONTENTS |
||
| ViewSonic projector, power cable, VGA cable, HDMI cable, remote control/laser with batteries, lens cap, Quick Start Guide, ViewSonic Wizard DVD (with User Guide), soft carrying case. |
開箱不良包換期限: 購機14天包換
產品保養期:
2年自攜保養; 包括零件及人工費.
(燈泡屬於耗材部份，僅提供一年保養, 且使用時間700小時內。)
由2011年12月起購買之投影機可享以下升級保養服務:
3年免費上門收送，保養; 包零件及人工費。
(燈泡屬於耗材部份，僅提供一年保養,且使用時間700小時內。)
Both HK & Macau provide on-site service for projector.
*on-site service is meaning pick up & delivery, not on-site repair.
